HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
10-8
Cleaning the Magnetic Encoder
Step Procedure
1 Open the front cover and remove the Film Cartridge.
2 Remove the Magnetic Cover to access the Magnetic Head.
3 Remove the Magnetic Head. See Display A below.
3 Use an alcohol wipe from the cleaning kit to clean the Magnetic Head. See
Display B below.
4 Replace the Magnetic Head and Magnetic Cover.
Display A
Display B
