RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.4)
8-53
Adjusting the Image Position controls
Use the Image Position controls to position the image on a card (to be adjusted).
Step Procedure
1 Adjust the Image Position values by clicking on the Vertical and Horizontal
adjustment arrows.
• These values ensure that the Cards always remain in the same position
as they travel through the Printer (regardless of image orientation).
• The Card Illustration (shown in the Image Position box) will flip and rotate
according to the selection of Portrait, Landscape or Rotate 180 Degrees.
• The outline around the illustration will always remain in the same
Landscape orientation.
