RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.4)
4-5
Installing the Flipper Module Accessory
Parts included: Flipper Module Accessory Kit, PCB-INTF Board, Torx tool and screws
Tools needed: Torx Tool (included in kit)
Estimated Repair Time: 20 minutes
Step Procedure
1
Caution: Power off the Printer by unplugging the power cord from
the Printer.
2 Remove all USB, Serial, Ethernet communication connections. Remove the
Card Output Hopper.
Important: Do not remove the Covers for this procedure.
3 The Flipper Module is installed at the output side of the Printer.
If there is a Lamination Module attached, the Flipper Module is placed in
between the Printer and Lamination Module.
4 a. Remove the Output Side Upgrade Cover (D910139-01).
b. Release the latch on the upgrade cover.
c. Pull on the bottom of the upgrade cover to remove it from the printer.
5 a. Turn the Printer and the Flipper Module on their back.
b. Use the Torx tool provided to remove the two (2) screws from the bottom
of the Flipper Module. Save the screws for later for reattachment.
6 Position the Flipper Module attachment tabs and the PCB-INTF Board into
the appropriate slots at the base of Printer. See Display A (below).
7 Use the two (2) screws to attach the Flipper Module to the Printer. Please
refer to the pictures below.
Continued on the next page
