Faria SmartCraft MG2000 - Lighting; Backlight Mode; Contrast Mode

and
Operation
Normal Mode
When the MG2000 is turned on, the unit
enters “Self Test” mode. The following
screen will be displayed for 10 seconds.
™
Networked
The horn will sound once, the warning
lights will flash, and the backlights will
flash. When this is complete, this screen
will appear for 2 seconds.
Note: If the key is turned on to the “accessory”
position and therefore there is no data being
received from the ECU the “ECU Data Error”
warnings will appear. This is normal as the
engine is not running.
Once the engine is running, the “Default”
screen will appear. If the “ECU Data Error”
warning continues to appear after the engine
is running, check all connections between
the engine and the MG2000.
The MG2000 then enters the “Normal”
mode.
Lighting
Brightness Mode
In the “Normal” mode, to adjust the
lighting intensity of all of the instruments
connected to the MG2000 tachometer
press the “Mode” button.
In the “Bightness” mode, the lighting
intensity can be changed by using the
“Down” or “Up” buttons.
Or
Contrast Mode
To enter the “Contrast” mode press the
“Mode” button, from the “Brightness”
mode. (To change the contrast from the
“Normal” mode press the “Mode” button
twice.)
In the “Contrast” mode the MG2000
display contrast can be adjusted by
pressing the “Down” or “Up” buttons.
Or
With the display in “Positive” mode, black
text on a white background, pressing the
“Down” button decreases the contrast
(make the text appear less dark).
Page 4
