EXTENDED MODE
CARD G / FIT 59 V 6.15 E / April 2010
Pressing the key
for 3 seconds
initializes all switching times to 0:00 (as described in the lower part of the display).
Three weekly timer programs have been pre-set which can be retrieved by pressing the key ,
or for 1 second. A number in the upper display on the left-hand side indicates the
selected program.
No pre-set program is activated in case of a missing number.
Customized data can be programmed and saved into the FIT-controller using one of these three
keys. The respective program is overwritten in this case.
The green message SAVED will occur if a program is stored to the FIT.
