EXTENDED MODE
CARD G / FIT 70 V 6.15 E / April 2010
The other parameters in this screen allows the operator to select the process data which are to
be included in the data recording.
The appropriate data will be transferred if ON is chosen.
The appropriate data will not be transferred if OFF is chosen.
Unintended power failures on the CARD G FIT unit may cause corrupted data
on the USB-stick. It is strongly recommended to backup these data
periodically.
The data on the USB-stick can be accessed through an Ethernet connection to
the FIT-controller. The IP addresses needs to be adjusted according to the
local network requirements (see chapter 17.10.2 on page 71). The process data
can then be accessed on drive c/ on the FIT-controller using the File Transfer
Protocol (FTP).
The key is to be used to return from this screen back to the screen CONVEYING MODE.
The key is to be pressed to return to the MAIN SCREEN.
