5. Testing parts
5-9
Festo P.BE-CB-COMP-EN en 1102d
5.4 Evaluation of the test results
5.4.1 Checking the features
The individual features of the inspection parts differ from the
average values of the sample part features. The Checkbox
ascertains the feature which differs most (maximum deviation)
for each test part.
A...
During the test procedure the inspection part deviation
will be shown for 1.5 seconds. Detailed instructions on test
part deviation (arithmetical algorithm) can be found in
Appendix A.3.3.
Value
Evaluation Note
≤ 100
Good part The smaller the v alue,
the more accurately the
inspection part corres-
ponds to the sample
parts.
> 100
Reject part The larger the value,
the less the inspection
part corresponds to the
sample pa rt s.
Indicating range: 0 to 999
Tab. 5/1: Inspection part deviation
