2.6 Error diagnostics
The Checkbox indicates operating errors as follows:
– The Checkbox switches automatically to the Stop status.
– The illuminated push-buttons on the Checkbox flash.
E...
F...
– The display shows error code E... or warning code F...
Key Status Significance
START/
STOP
STATUS/
TEACH
Flashes red
Flashes yellow
Error message/warning
Tab. 2/5: Error display
Code E...
Type Explanation
01 ... 19 Ambient fault Fault in power supply, parts supply;
dirt y lens etc.
20 ... 21 Recognition
fault
Orientations or sample parts cannot
be distinguished.
40 ... 43 Data fault Teach data, configuration data or
system parameters are not
compatible or do not exist
>=60 Hardware
fault
Internal fault (can only be eliminated
by cust omer support)
Tab. 2/6: Types of faults (overview)
