5. Testing parts
5-4
Festo P.BE-CB-COMP-EN en 1102d
5.2 Test mode
Stop
The Teach procedure is concluded and the Checkbox is
ready to operate (Stop status)
Set the desired parts type via the PLC interface (Chapter 3.6.3)
1. Provide inspection parts for each parts type
S Use good, bad and incorrectly oriented parts from the
parts assortment.
S Test a sufficient number of parts in order to obtain a
reproducible result.
Show, for example, 6 good parts per orientation as
well as 6 bad parts.
15
2. Press the button STAR T/STOP (AUTO mode). T est parts
from the displayed parts type (e.g. 1) with the factory-set
tolerance of 5%.
3. You do not need to be very careful when placing the parts
on the conveyor belt.
If possible, use the conveyor device intended for the
inspection of workpieces. The inspection parts should be
positioned (at random), as in normal operation.
E05
If the supply of parts is interrupted for a long period, the
Checkbox will show fault message E 05 or warning F 05 and
will stop automatically (see Chapter 2.6 and Appendix A.1.2).
4. Check the test results e.g. with regard to the following
aspects: Have the orientations been recognized correctly?
Is the grading of the parts recognized as good/bad
correct?
