5. Testing parts
5-10
Festo P.BE-CB-COMP-EN en 1102d
5.4.2 Checking the orientation
The Checkbox ascer tains during the test procedure whether
the orientation of the last scanned test part can be assigned
to the orientatio ns of the sample part.
#...
The uncertainty in orientation recognition will be shown
for 1.5 seconds after the display of the inspection part
deviation.
Value
Evaluation Significance
< 100
Inspection part
orientation can be
assigned
The smaller the v alue,
themorereliablythe
inspection part
orientation will be
recognized.
> 100
Inspection part
orientation cannot be
assigned clearly
The larger the value,
the less reliably the
inspection part
orientation will be
recognized.
Indicating range: 0 to 999
Tab. 5/2: Uncertainty of orientation recognition
