1. S ystem summary
1-4
Festo P.BE-CB-COMP-EN en 1102d
1.2 Software packages for the Checkbox
Various software packages are available for user-friendly
commissioning, optimizing and monitoring. They have been
specially developed for the products in the Checkbox family
and can be used with all devices in the Checkbox family.
Software
Package
Functions
CheckKon
Checkbox
Configurator
– Display and assessment of the last
registered test part
– Displaying and logging of the parts contour
as well as the characteristic s derived from
the contour.
– Displaying the light intensity recognized by
the camera
– Displaying and printing out of the system
configuration
– Displaying and modifying the system para-
meters
– Loading a new operating system into the
Checkbox
CheckOpti
Checkbox
Optimizer
– Convenient teaching of the sample parts
– Monitored testing of parts, displaying the
features registered
– Evaluation of the inspection of workpieces
with regard to reliability (evaluation)
– Graph ic display of the test sequence
– Optimization of the inspection of work-
pieces through manual adaptat ion of the
min./max. values of the Teac h data or
through configuration tools
– Support in project planning, management
and documentation
Tab. 1/1: Software package
The CheckKon software package, operating system updates
and current product information on the Checkbox Compact
can be found in the Festo Internet pages under the address
www.festo.com in the area “Suppor t / Downloads”.
