2. Fitting and commissioning
2-13
Festo P.BE-CB-COMP-EN en 1102d
2.4 Adapting system parameters with CheckKon
A password is required for CheckKon for setting the system
parameters and transmitting the modifications to the
Checkbox (Function “Modify system”). You can obtain your
password via the service hotline +49 / 711 / 347-1610. The
function “Observe system” can be used without a password.
1. Install CheckKon on your diagnostic PC. Notes on
installation can be found in the software manual.
2. Connect the Checkbox at the DIAG connection with the
diagnostic PC (see Chapter 3.4). Connect the devices only
when the power supplies are switched off.
Diagnostic mode S tart CheckKon when the Checkbox has been switched on.
When Checkkon is started, it carries out a system test and
switches the Checkbox to the diagnostic mode.
Note
In diagnostic mode the Checkbox transmits additional
information via the diagnostic interface. During the
transmission time no parts are checked.
• Do not operate the Checkbox in diagnostic mode with
thefullrateofparts.
In this way you can prevent parts from passing the
actuator positions unchecked.
1. Adapt the Checkbox to your system requirements with
the system parameters in the menu [Window] [S ystem
parameters]. Note also the instructions in the following
chapters and in the software manual.
