2. Fitting and commissioning
2-14
Festo P.BE-CB-COMP-EN en 1102d
CheckKo n shows the most important system parameters
through the menu [Window] [System parameters] symbol
“Only important parameters”. Make sure that these para-
meters are adapted to your application.
2. Transfer the modified settings to the Checkbox
(see software manual).
3. Conclude CheckKon and with it the diagnostic mode when
all settings have been completed.
Note
Faulty processing data can cause incorrect functioning of
the Checkbox.
• Carry out the complete Teach procedure again if you
have modified the system parameters with CheckKon.
