2. Fitting and commissioning
2-19
Festo P.BE-CB-COMP-EN en 1102d
AUTO mode E v aluate the reliability of the Teach data before you begin
with the automatic parts test.
Note
The following list provides only an o verview of the most
impor tant operating steps.
• Note the instructions on the test procedure in Chapter 5,
before you start the Checkbox in the AUTO mode.
Stop
The Checkbox is ready to operate (Stop status).
15
A...
#...
1. Press START/STOP button.
Presetting: Parts type 1; tolerance 5 % (influence and
setting tolerance, see Chapter 5.3)
2. Check the inspection part deviation “A” and the inspec-
tion part orientation “#” (see Chapter 5.4).
3. If necessary, correct the system settings with CheckKon.
Note
Faulty processing data can cause incorrect functioning of
the Checkbox.
• Carry out the complete Teach procedure again if you
have modified the system parameters with CheckKon.
4. Conclude CheckKon when all the settings have been com-
pleted.
Switching off Switch the Checkbox to the Stop status before switching it off.
Stop
1. Press START/STOP button.
2. Switch off the operating voltage.
