2. Fitting and commissioning
2-18
Festo P.BE-CB-COMP-EN en 1102d
TEACH mode Scan the sample parts in the TEACH mode in order to record
the Teach data.
Note
The following list provides only an o verview of the most
important operating steps. Note the instructions on the
Teach procedure in Chapter 4, before you start the
Checkbox in the TEACH mode.
Stop
The Checkbox is ready to operate as soon as it is switched
on (Stop status).
1o1
C30
1. Press button STATUS/TEACH.
Scan the sample parts of parts type 1 in orientation 1.
During scanning the “C” value of the characteristic
scatter will be shown (e.g. 30)
1o2
2. Press STATUS/TEACH button.
Scan sample parts in the next orientation (2).
Repeat the procedure for further orientations.
Stop
3. Press START/STOP button.
TheTeachdatawillbesavedandtheTEACHmodewillbe
concluded.
