A. Technical appendix
A-23
Festo P.BE-CB-COMP-EN en 1102d
Dimensions
Height (without plug) 241 mm
Width 60 mm
Length 150 mm
Inside passage of the optical channel 60 mm
Inside height of the optical channel 40 mm
Tab. A/15: Technical data: Dimensions
Electrical properties of the I/O signals
Outputs – All outputs electronically limited to max. 700 mA
– Max. residual current at “PLC” c onnection: 1 A
Tab. A/16: Technical data: Electrical properties
Camera and lighting
Camera resolution 6/100mm
Exposure t ime 128 ... 1024 ìs
Laser class Laser class 2 according to E N 60825-1:1994
+ A1:2002 + A2:2001
(Class I I according to CFR 21 §1040.10 USA).
P≤1mW
ë = 645 ... 665 nm
Tab. A/17: Technical data: Camera and lighting
