2. Fitting and commissioning
2-9
Festo P.BE-CB-COMP-EN en 1102d
Connection Plugs/sockets
Power supply socket PG 9 or PG 13.5
Sensors, actuators PG 7
Tab. 2/2: Connection
In order to guarantee observance of the IP protection class
for the completely fitted Checkbox:
S tighten the union nuts of the plugs by hand
S seal unused sockets with the protective caps supplied.
Caution
L ong I/O signal lines reduce the resistance to interference.
• Comply with the maximum permissible I/O signal line
length of 30 m.
