1
Click the catalogue icon. You then open the hard-
ware catalogue.
2
Mark the station type "FESTO CP FB13"
(\PROFIBUS-DP\Additional FIELD DEVICE-
S\VALVES) in the hardware catalogue with the left-
hand mouse button. The slave type "VALVES" will
appear under the file "Additional FIELD DEVICES"
when you have copied the GSD (see step 1 in the
preparations).
3
Hold the left-hand mouse button pressed down and
pull the cursor onto the graphic PROFIBUS line on
the DP master (drag and drop).
4
The mask "Selecting the Setpoint Configuration" will
appear. Select here the highest occupied string
number and confirm this with OK.
5
The entry mask "Properties - PROFIBUS Node" will
appear. Select the slave (PROFIBUS) address
identical to the setting of the rotary switch/DIL switch
(see Chapter 1.2.1) on the slave and confirm this
with OK.
The icon of the valve terminal will appear on the
PROFIBUS line (see Fig. 2/10).
2. Commissioning
CP FB13-E 9904b 2-23
