Festo Controller CECC
22
4 Commissioning
4.1 Preparations
Administrator rights are required to install the CODESYS V3 pbF programming software on your
PC.
1. Install the CODESYS V3 pbF programming software on the PC used to commission, configure and
program the CECC.
2. Install required packages (CECC) if necessary. To do this, open the Package Manager in Codesys using the
[Package Manager] command in the [Tools] menu.
3. After the last package is installed, restart Codesys to be able to use the modified plug-ins.
4. Connect the PC to the CECC directly via the Ethernet interface or indirectly via a switch/hub.
4.2 Getting started
• Launch CODESYS V3 pbF. You will find the program on your Windows PC in the Start menu directory
[Programs] [Festo Software] [CODESYS V3].
4.2.1 Creating a project
• Create a new project ([File] [New Project...]), enter a name and the storage location and confirm your
entries by clicking "OK".
Figure: "New Project" dialog
