Festo Controller CECC
23
4.2.2 Selecting a device
1. Select the relevant device in the "CECC Project" dialog.
• Check the "Show all device versions" box for an extended selection of older device variants.
The respective version of the relevant device description file is appended to the name of the
selected device.
Figure: "New Project" dialog – selecting the device
2. Select a programming language, e.g. structured text (ST).
3. Select the relevant interfaces.
Figure: "New Project" dialog – selecting the interfaces
Options not supported by the respective device are inactive (shown in grey) and cannot be
selected.
