Festo Controller CECC
51
The sub-tabs contain the following information and setting options:
Sub-tab Comment
IO-Link Device Shows the IO-Link specification
Settings
– Data width for the process data
– Baud rate for the data transmission
I/O Mapping Current process data for the controller as an IO-Link device.
Status Status of communication
Information Version information for the CECC as an IO-Link device.
Figure: Sample I/O mapping for the CECC as an IO-Link device
