4. Commissioning
4-14
Festo P .BE-MPA-EN en 1108e
Note
The manual override cover caps serve for limiting the
function of the manual override and are constructed so
that they can only be remo ved with a great deal of
strength. During dismantling the snap hooks of the cover
will be damaged.
Dismounting Proceed as follows:
• Use a suitable screwdriver to lift the manual override caps
out of the manual overrides (see fig.):
Fig. 4/4: Dismounting the manual override cover caps
