1. Summary of components
1-16
Festo P .BE-MPA-EN en 1108e
Further information on the valves can be found in Appendix B.
Proportional-pressure regulator
The VPPM-...TA-... proportional-pressure regulator is intended
to regulate a pressure proportional to a specified setpoint
value. An integrated pressure sensor records the pressure at
the work connection and compares this with the setpoint
value. In the event of deviations between the setpoint/actual
values, the valve regulates until the output pressure has
reached the setpoint value.
For constant pressure supply, which is necessary for accurate
control quality, the proportional pressure regulator has an
additional supply connection.
Configure the proportional pressure regulator via the PLC or
the Festo Handheld (CPX-MMI).
Mounting of the proportional-pressure regulator is described
in the mounting instructions VPPM-...TA-...
Information on configuring the proportional-pressure
regulator is provided in the MP A-... electronics description.
Identification of the
proportional pressure
regulator
The proportional pressure regulators on the MPA-S valve
terminal are marked by identification codes. With this
identification you can ascertain the type of proportional
pressure regulator.
Ident. code
Proportional pressure regulator, normally closed ...
VPPM-6TA VPPM-8TA
2 % accuracy:
QA QG 0 ... 2 bar out put pressure
QB QH 0 ... 6 bar output pressure
QC QK 0 ... 10 bar output pressure
