3. Installation
3-25
Festo P.BE-MPA-EN en 1108e
3.4.2 Connecting the electric cables
Warning
• Use only PELV circuits as per IEC/EN 60204-1 (protective
extra-low voltage, PELV) for the electric power supply.
• Also observe the general requirements for PELV circuits
in accordance with IEC/EN 60204-1.
• Only use power sources which guarantee reliable electrical
isolation of the operating voltage as per IEC/EN 60204-1.
Protection against electric shock (protection against direct
and indirect contact) is guaranteed in accordance with
IEC/EN 60204-1 by using PELV circuits (electrical equipment
of machines, general requirements).
Note
Check within the framework of your EMERGENCY STOP
circuit to ascertain the measures necessary for putting
your machine/system into a safe state in the event of an
EMERGENCY STOP (e.g. switching off the operating voltage
for the valves and output modules, switching off the
compressed air).
MP A-F valve terminal with multi-pin plug connection:
Instructions on connecting the electric elements of the MP A-S
valve terminal with multi-pin plug connection can be found in
the package insert.
MPA-F valve terminal with CPX terminal:
Instructions on connecting the operating voltage can be
found in the system description of your CPX terminal.
Detailed instructions on connecting the CPX modules
(bus node, I/O modules etc.) can be found in the relevant
descriptions for the CPX module (see the system description
of your CPX terminal, table “Descriptions of the CPX
terminal”.
