3. Installation
3-32
Festo P .BE-MPA-EN en 1108e
3.5.2 MPA-S valve terminal with CPI module or AS-Interface
Instructions on addressing the pneumatic modules can be
found in the leaflet supplied with the product.
3.5.3 MPA-S valve terminal with multi-pin plug connection
– Assign the addresses in ascending order witho ut gaps
(see example).
– Address assignment does not depend on whether
blanking plates or valve plates are fitted.
– Depending on the electronics modules a valve position
occupies the following number of addresses:
Number
addresses
Electronics module
MPA1 MPA2
one addre ss VMPA1-MPM-EMM-4 VMP A2-MPM-EMM-2
two addresses VMP A1-MPM-EMM-8 VMPA2-MPM-EMM-4
Tab. 3/8: Electronics module for multi-pin plug connection
– If a valve location occupies 2 addresses, the following
applies:
– solenoid coil 14 occupies the lower-val ue address,
– solenoid coil 12 occupies the higher-value address.
