1. Summary of components
1-8
Festo P .BE-MPA-EN en 1108e
1.3 Valve terminal design
The MPA-S valve terminal consists of the following pneumatic
and electrical components: The most important components
are shown in the following Fig.
12 3
4
5
6
7
8
1
3
9
aJ
2 3
9
aJ
aJ
aA
1
Flat plate silencer or exhaust plate
2 Cover plate
3 Valves
4 Pressure sensor plate
5 Electrical supply plate
6 Proportional-pressure regulator
7 Right end plate
8 Pneumatic supply plate
9 Pressure regulator plate
aJ Sub-base
aA Multiple connector plate; AS interface,
CPI interface or pneumatic interface
Fig. 1/5: Main components of the MP A-S valve terminal
