2. Fitting
2-13
Festo P.BE-MPA-EN en 1108e
2.3 Mounting/removing the inscription label holder
An inscription label holder can be mounted onto each
sub-base to enable the valves or work connections to be
distinguished.
Informationonaccessoriescanbefoundinthe
Festo Catalogue (see www.festo.com\catalogue).
Mounting Proceed as follows:
• Clip the inscription label holders into the grooves in the
sub-bases (see diagram):
1 Fixture for the
inscription label
holder on the
sub-base
2 Inscription label
holder
1
2
Fig. 2/4: Mounting the inscription label holder
