4. Commissioning
4-19
Festo P.BE-MPA-EN en 1108e
VPPM-…TA-... Output pressure with
signal 1 % FS
1) 2)
Output pressure with
signal 100 % FS
1) 2)
2bartype 0.02 bar 2bar
6bartype 0.06 bar 6bar
10 bar type 0.1 bar 10 bar
1)
FS = Full scale (1 % FS = 0.1 V / 100 % FS = 10 V)
2)
0V=0bar
Tab. 4/8: Output signal of the propor tional pressure regulator
Additional important specifications on commissioning the
proportional-pressure regulator, such as parametrisation,
significance of the LED display, can be found in the MPA-...
electronics description.
