5. Maintenance and conversion
5-11
Festo P.BE-MPA-EN en 1108e
Before mounting the electronics module
There are different designs of the electronics module
depending on the connection variant.
Electronics modules for the MPA-S valve terminal with CPX
terminal
Caution
Damage to components and functional damage
It is not permitted to supply M PA pneumatic modules that
are equipped with electronics modules and have a
common circuit via interlinking blocks of type
CPX-GE-EV-V... (valve supply) or 5-pin system supply
(type CPX-GE-EV-S-7/8-5POL).
• If your M PA-S pneumatics are equipped with electronics
modules of type VM PA1-FB-EMS-... or
VMPA2-FB-EMS-..., you must supply the MPA-S
pneumatics exclusively via a four pin system supply
module of type CPX-GE-EV-S or CPX-GE-EV-S-7/8-4POL
of the CPX terminal.
Observe the overview in Tab. 5/2.
