5. Maintenance and conversion
5-16
Festo P .BE-MPA-EN en 1108e
1 Mounting screws of
the valve or blanking
plate
2 V alve or blanking
plates
3 Cord seal
4 Electronics module
5 Sub-base
6 Inscription label
holder
7 The seals of the
electronics module
8 Mounting screws of
the electronics
module
9 2 conical ring seals
per valve or blanking
plate
1
2
3
4
5
6
9
8
7
Fig. 5/5: Dismantling and mounting the electronics module (example MPA1)
