5. Maintenance and conversion
5-39
Festo P.BE-MPA-EN en 1108e
Necessary components
For extension you will require:
Components
Type
One of the following electric MPA supply plates:
– With plug M18, (3-pin)
– With plug 7/8” (4-pin)
– With plug 7/8” (5-pin)
VMPA-FB-SP-V
VMPA-FB-SP-7 /8-V-4POL
VMPA-FB-SP-7 /8-V-5POL
Also a seal without channel separation or a separating seal with
channel separation
See Chapter 1, Tab. 1/8
Tab. 5/11: Electrical supply plates
Mounting Proceed as follows:
1. Loosen the electric and pneumatic connections and
removetheMPA-Svalveterminalfromitsfastening
surface (see Chapter 5.2).
2. Mount the electric supply plate as described in the
VMPA-FB-SP-...-V-... assembly instructions.
3. Mount the MP A-S valve terminal onto the mounting
surface (see Chapter 2 Fitting, “Mounting onto a wall” or
“Mounting onto an H-rail”).
4. Then install the pneumatic and electrical connections
(see Chapter 3 “Installation, connecting the MPA-S valve
terminal”).
