A. Technical appendix
A-6
Festo P .BE-MPA-EN en 1108e
General
Vibration and shock
1) 2) 4)
–Vibration
– Shock
– Continuous shock
Tested as per DIN/I EC68 / EN60068 parts 2 - 6
With horizontal H-rail fitting: Severity level 1
With wall mounting:
2) 3)
Tested as per DIN/I EC68 / EN60068 parts 2 - 27
With horizontal H-rail fitting: Severity level 1
With wall mounting:
2) 3)
Tested as per DIN/I EC68 / EN60068 par ts 2 - 29,
With wall and H-rail mounting: Severity level 1
1)
Specifications on vibration and shock of the CPX terminal can be found in the manual for the
CPX system.
2)
MPA-S valve terminal with CPX t erminal:
– up to a length of 280 mm between the pneumatic interface and the right-hand end plate,
without additional fastening: Severity level 2
– as from a length of 280 mm between the pneumatic interface and the right-hand end plate,
with additional fastening on the pneumatic supply plates: Severity level 2
3)
MPA-S valve terminal with CPI, with A SI or with multi-pin plug connection:
– up to a length of 280 mm of the valve terminal without additional fastening Severity level 2
– as from a length of 280 mm of the valve terminal with at least one additional fastening in
the centre of the valve terminal to the pneumatic supply plate: Severity level 2
4)
See following table for explanations of the severity levels.
Tab. A/2: Vibration and shock
Severity
level
Vibration Shock Continuous shock
1 0.15 mm travel at 10-58 Hz;
2 g acceleration at 58-150 Hz
±15 g at 11 ms duration;
5 shocks per direction
±15 g for 6 ms duration;
1000 shocks per direction
2 0.35 mm travel at 10-60 Hz;
5 g acceleration at 60-150 Hz
±30 g at 11 ms duration;
5 shocks per direction
-----
Tab. A/3: Values for vibration and shock as per DIN/IEC68
