B. Supplementary component summary
B-3
Festo P.BE-MPA-EN en 1108e
B.1 Overviewofvalvepositioncomponents
If the designations of the connections and control elements
on the valve terminal differ from the logical designation of the
circuit symbols, the designations of the connections and
control elements are specified additionally in the circuit
symbols in brackets.
Note
MP A-S valve terminal with multi-pin plug connection and
modular electrical linking (type MP A-MPM-...):
The number of addresses that a module occupies depends
on:
– the corresponding electronics module
(see Chapter 3, Tab. 3/8)
– the corresponding interlinking board
(see Chapter 5, Tab. 5/5)
