Festo MPA-FB-VI - Page 93

3. Installation
3-21
Festo P.BE-MPA-EN en 1108e
Cable Connection code
(ISO 5599)
Connection size
(ISO 228)
Connection
1)
Compressed air or
vacuum
(1) G¼” Fitting in electrical interface or in
the pneumatic supply plate
Pilot air (external
pilot air supply)
(12/14) M7 Fitting in electrical interface or in
the multi-pin plug connection plate
Ducted exhaust
air from the valves
(3/5) QS10 Fitting in exhaust plate
2)
Ducted exhaust
from the pilot
control
(82/84) M7 Fitting in the
supply plate
2)
Work air or
vacuum
(2) or (4) MPA1: M7
MPA2: GÁ”
Fitting in the sub-base
Connection for
external pressure
P1 M7
Fitting in pressure sensor plate type
VMPA-FB-PS-P1
Pressure input
Pressure output
Exhaust air of
VPPM-…TA
(1)
(2)
(3)
G¼”
G¼”
G¼”
Fitting in the sub-base of the
proportional pressure regulator
1)
Depending on what you have ordered, the MPA-S valve t erminal may already be fitted with QS
fittings.
2)
Only with MPA-S valve terminals with exhaust plate or supply plate
Tab. 3/4: Assignment of the connections
