Festool CONTURO User Manual

1 12 2
3 34 4
2524
3
Adjusting the edging height
Use the rotary knob to adjust the edging height until the
edge band touches at the top and bottom. Then turn back
the switch 1–2 locking positions so that there is some play
in the edge band.
Slide the edge band into the edging infeed.
NOTE Note that the edging height can only be adjusted at
operating temperature.
Briefly press the start button. When the symbol for inserting the edging appears, guide the
edging into the active infeed until it is drawn in. When the tick
mark appears on the display, the edging has reached starting
position and the machine is ready for gluing.
2014_FES_EN_CONTURO.indb 25 11.12.13 11:51

Festool CONTURO Specifications

General

Power consumption	1200 W
Edge height	18-65 mm
Edge thickness	0.5-3.0 mm
Melting temperature	100-210 °C
Weight	7.9 kg
Inside radius	> 50 mm
Heating time	8 min
Feed speed	2/4 m/min
Dust extraction connection diameter	27 mm
