Festool CONTURO User Manual

500
87,5 87,5325
Ø 0,6
250
60
193
12
Ø 0,6
Ø 0,6
Ø 0,6
Ø 0,6
Ø 0,6
73
72
6
Working with dust extraction
When working with the CONTURO, you can extract any vapours with a Festool mobile dust extractor – which
makes tasks that take longer more pleasant. There is an extractor connector located behind the machine,
which can be attached to a Festool suction hose D 27.
All Festool mobile dust extractors are suitable for dust extraction. Vapours are discharged away from working
area, but remain within the room. The CT 17 mobile dust extractor also offers the possibility of connecting
a second suction hose to discharge the exhaust air outside.
2014_FES_EN_CONTURO.indb 73 11.12.13 11:52

Festool CONTURO Specifications

General

Power consumption	1200 W
Edge height	18-65 mm
Edge thickness	0.5-3.0 mm
Melting temperature	100-210 °C
Weight	7.9 kg
Inside radius	> 50 mm
Heating time	8 min
Feed speed	2/4 m/min
Dust extraction connection diameter	27 mm
