Festool CONTURO User Manual

1 2
3 4
27
26
3
3.3 Mobile gluing of edges
MFT
VAC SYS
The CONTURO is now ready to start fixing the edging to the work-
piece. The most important thing is that the workpiece is clamped
securely. You can work on the Festool multifunction table MFT/3
either with screw or lever clamps, or use the Festool VAC SYS vacuum
clamping system or a combination of both. The VAC SYS system
was used in our example because the workpiece is accessible from
all sides – ideal for fixing edging to round workpieces.
Refer to the chapter “Tips and tricks” for further information on working with
the VAC SYS and MFT/3 as well as a plan of a workstation.  Page 66
2014_FES_EN_CONTURO.indb 26 11.12.13 11:51

Festool CONTURO Specifications

General

Power consumption	1200 W
Edge height	18-65 mm
Edge thickness	0.5-3.0 mm
Melting temperature	100-210 °C
Weight	7.9 kg
Inside radius	> 50 mm
Heating time	8 min
Feed speed	2/4 m/min
Dust extraction connection diameter	27 mm
