–54–
✱
67 RF XMTR LOW BATTERY REPORT CODE ÊÊ0ÊÊ|ÊÊ0ÊÊ
This is sent in the event that a wireless transmitter low battery
condition exists. (See box)
✱
68 CANCEL REPORT CODEÊÊÊÊ(See box on previous page.)ÊÊ ÊÊ0ÊÊ|ÊÊ0ÊÊ
This is sent upon disarming of the system after an alarm condition
was reported.
RESTORE
REPORT CODES
(✱70Ð✱ 76)
✱70 ALARM RESTORE REPORT CODE, 1st DIGIT Ê ÊÊ0ÊÊ
This is sent when the zone that caused an alarm is restored to its
non-faulted condition. 2nd digit is automatically sent as the 2nd digit
of the zone alarm report code programmed in field ✱56, if expanded or
4+2 reporting is selected.
✱
71 TROUBLE RESTORE REPORT CODE ÊÊ0ÊÊ|ÊÊ0ÊÊ
See box. This is sent when a trouble in a zone is restored.
✱
72 BYPASS RESTORE REPORT CODE ÊÊ0ÊÊ|ÊÊ0ÊÊ
See box. This is sent when a zone that has been bypassed is un-
bypassed.
✱
73 AC RESTORE REPORT CODE ÊÊ0ÊÊ|Ê0ÊÊÊ
This is sent when AC power has been restored after an AC power
outage. See box. Reports with Partition 1 Subscriber No.
✱
74 LOW BAT RESTORE REPORT CODE ÊÊ0ÊÊ|ÊÊ0ÊÊ
This is sent when a system low battery condition is restored to
normal. See box on previous page. Reports with Partition 1
Subscriber No.
✱
75 RF XMTR LOW BATTERY RESTORE CODE ÊÊ0ÊÊ|Ê0ÊÊÊ
See box. This is sent when a transmitter that previously sent in a low
battery message has sent a message indicating it no longer has a low
battery condition.
✱
76 TEST RESTORE REPORT CODE ÊÊ0ÊÊ|ÊÊ0ÊÊ
This is sent when the test mode is exited. See box. Reports with
Partition 1 Subscriber No. A restore code entered
here will cause a restore message to be sent when Test mode is exited.
✱
89 EVENT LOG 80% FULL REPORT CODE ÊÊ0ÊÊ|ÊÊ0ÊÊ
If an Event Logging selection is made in field
✱
90, a message can be
sent to the central station receiver when the log is 80% full. If the log
becomes full, a new message will overwrite the oldest message in the
log. Note: Aside from the selection made by the installer in field
✱
90,
all control and readout from the log is accomplished via the
Downloader.
✱
90 EVENT LOGGING Ê ÊÊ3ÊÊ
0 = No event logging
1 = log Alarm/Alarm Restore
2 = log Trouble/Trouble Restore
4 = log Bypass/Bypass Restore
8 = log Open/Close
x = log combination of events (add value of entries) Example: ÊTo select
ÒAlarm/Alarm RestoreÓ, and ÒOpen/CloseÓ, enter 9 (1 + 8); to select
all events , enter #15. Press [#] first to enter 2-digit options.
The default of Ò3Ó = alarm/alarm restore (1) plus trouble/trouble
restore (2).
