² progressive speed by VCS
³ 0,35 l/kW electrical power, the randomized values between 30 % and 80 %
of the rated speed
Fig. 9.8-5: Technical data
Idle running speed ² 2900 rpm 3000 rpm 3000 rpm 2900 rpm
Valve clearance (engine cold) 0,2 mm Hydro Hydro 0,2 mm
Cylinder head nut torque 63,7 - 68,6 Nm 68 Nm 68 Nm 25 Nm
Compression ratio 22,5:1 22:16 22:16 22:1
Lubrication oil capacity 6,0 l 6,4 l 6,4 l 7,5 l 7,5 l
Fuel consumption ³ approx. 2,7 - 7,1 l approx. 4,9-13,1 l approx. 3,78-
10,1 l
approx. 6,3 - 16,8 l approx. 6,7 -
17,9 l
Oil consumption max. 1 % of fuel consumption max. 0,5 % of fuel consumption
Oil specification API CF API CF API CF-4 API CF API CF
Cooling water requirement for seawater
circuit (Marine generators only)
40-50 l/min 40-50 l/min 40-50 l/min
Permissible max. permanent tilt of engine a) 25° crosswise to the longitudinal axis
b) 20° in longitudinal direction
Recommend starter battery size 12 V 70 Ah
equivalent
12 V 88 Ah
equivalent
12 V 88 Ah
equivalent
12 V 95 Ah
equivalent
12 V 95 Ah
equivalent
Recommend cable cross size starter battery
cable
Length 4 meter max.
25 mm² 50 mm² 50 mm“ 70 mm² 70 mm²
Max. exhaust back pressure 10,7 kPa
107 Millibar
10 kPa
100 Millibar
10 kPa
100 Millibar
Panda 30 IC Panda 40 LN Panda 47 LN Panda 60 MB Panda 75 MB
Panda 7,5-4 Panda 9-4 Panda 12-4 Panda 17-4 Panda 22-4
Type Kubota D905 Kubota D1105 Kubota V1505 Kubota V2203 Kubota V2403
Governor mechanic + VCS VCS VCS VCS VCS
Automatic start booster no no no no no
Cylinder 33444
Bore 72 mm 78 mm 78 mm 87 mm 87 mm
Stroke 73,6 mm 78,4 mm 78,4 mm 92,4 mm 102,4 mm
Stroke volume 898 cm³ 1123 cm³ 1498 cm³ 2197 cm³ 2434 cm³
Max. power (DIN 6271-NB) at 3000 rpm 17,5 kW 18,7 kW 23,3 kW 20,1 kW 31,1 kW
Rated speed 1500 rpm 1500 rpm 1500 rpm 1500 rpm 1500 rpm
Idle running speed ² 1500 rpm 1500 rpm 1800 rpm 1500 rpm 1800 rpm
Valve clearance (engine cold) 0,145 - 0,185 mm 0,145 - 0,185 mm 0,2 mm 0,2 mm 0,18 - 0,22 mm
Cylinder head nut torque 63,7 - 68,6 Nm 63,7 - 68,6 Nm 68 Nm 68 Nm 93,1 - 98 Nm
Compression ratio 23:1 23:1 22:1 22:1
Lubrication oil capacity 5,1 l 5,1 l 6,0 l 9,5 l 9,5 l
Fuel consumption ³ 0,7 - 1,8 l 0,84 - 2,24 l ca. 1,20-3,36 l ca. 1,8-4,9 l approx. 1,95 -
5,2 l
Oil consumption max. 1 % of fuel consumption
Oil specification API CF API CF API CF API CF API CF
Cooling water requirement for seawater
circuit (Marine generators only)
6-28 l/min 28-40 l/min 28-40 l/min 28-40 l/min 40-50 l/min
Permissible max. permanent tilt of engine a) 25° crosswise to the longitudinal axis
b) 20° in longitudinal direction
Recommend starter battery size 12 V 65 Ah
equivalent
12 V 65 Ah
equivalent
12 V 70 Ah
equivalent
12 V 120 Ah
equivalent
12 V 136 Ah
equivalent
Recommend cable cross size starter battery
cable
Length 4 meter max.
25 mm² 25 mm² 25 mm² 70 mm² 70 mm²
