Panda xControl
10.6.16 Kapitel/Chapter 11: Panda xControl - Seite/Page 179
11.2 Failure
11.2.1 Symbols and Messages in the Display
11.2.1.1 Message sample „Sensor defect“
Fig. 11.2.1.1-1: Sensor defect symbolicA soon as a defect sensor is detected, the xControl
shows it in the display
Fig. 11.2.1.1-2: Sensor defect english
Fig. 11.2.1.1-3: Sensor defect german
11.2.1.2 Message sample sensor/cable broken
Fig. 11.2.1.2-1: Sensor broken symbolicIf the sensor or the cable is broken following messages
appear:
