Fischer Panda 8000x - Single Phase Fan Control PXET6 Q

Installation Instructions
Seite/Page 90 - Kaptitel/Chapter 5: Installation Instructions 10.6.16
5.23 Electronic fan control for single phase fans PXET6Q_Ziehl Abegg
The electronic fan control variety the fan rpm stepless.
5.23.1 Preset for the use with Fischer Panda generators
The Ziehl Abegg fan control is preset for the use with Fischer Panda generators. For the preset following data and
jumper settings are used.
Fig. 5.23-1: Preset
