Appendix
Seite/Page 146 - Kaptitel/Chapter 9: Appendix 10.6.16
³ 0,35 l/kW electrical power, the randomized values between 30 % and 80 %
of the rated speed
Fig. 9.8-8: Technical data igenerators
Idle running speed 2900 rpm 2900 rpm 3100 rpm 2900 rpm 1800 rpm
Valve clearance (engine cold) 0,16 - 0,20 mm 0,2 mm 0,2 mm 0,2 mm 0,2 mm
Cylinder head nut torque 58,8 - 63,7Nm 42Nm 42Nm 42mm 68Nm
Compression ratio -- 23:1 24:1 24:1 22:1
Lubrication oil capacity 1,3 l 2,8 l 2,8 l 3,7 l 6,0 l
Fuel consumption ³ approx. 0,42 -
1,12 l
approx. 0,7-1,8 l approx. 1,0-2,66 l approx. 1,3-3,6 l approx. 1,20-
3,36 l
Oil consumption max. 1 % of fuel consumption
Oil specification API CF API CF API CF API CF API CF
Cooling water requirement for seawater
circuit (Marine generators only)
-- 16-28 l/min 16-28 l/min 16-28 l/min 28-40 l/min
Permissible max. permanent tilt of engine a) 25° crosswise to the longitudinal axis
b) 20° in longitudinal direction
Recommend starter battery size 12 V 28 Ah
equivalent
12 V 28 Ah
equivalent
12 V 36 Ah
equivalent
12 V 52 Ah
equivalent
12 V 70 Ah
equivalent
Recommend cable cross size starter battery
cable
Length 4 meter max.
25 mm² 25 mm² 25 mm² 25 mm² 25 mm²
Max. exhaust back pressure -- 9,3 kPa
93 Millibar²
9,3 kPa
93 Millibar
9,3 kPa
93 Millibar
10,7 kPa
107 Millibar
Panda 5000i Panda 8000i Panda 10000i Panda 15000i Panda 25i
Panda 45i
Type Kubota V2403
Governor iControl2
Automatic start booster no
Cylinder 4
Bore 87 mm
Stroke 102,4 mm
Stroke volume 2434 cm³
Max. power (DIN 6271-NB) at 3000 rpm 31,1 kW
Rated speed 2700 rpm
Idle running speed 1600 rpm
Valve clearance (engine cold) 0,18 - 0,22 mm
Cylinder head nut torque 93,1 - 98 Nm
Compression ratio
Lubrication oil capacity 9,5 l
Fuel consumption ³ approx. 1,95 -
5,2 l
Oil consumption max. 1 % of fuel consumption
Oil specification API CF
Cooling water requirement for seawater
circuit (Marine generators only)
55-80 l/min
Permissible max. permanent tilt of engine a) 25° crosswise to the longitudinal axis
b) 20° in longitudinal direction
Recommend starter battery size 12 V 136 Ah
equivalent
Recommend cable cross size starter battery
cable
Length 4 meter max.
70 mm²
Max. exhaust back pressure 10,7 kPa
107 Millibar
