EasyGrid User Guide MAN-00084 R 11.0
52
Protocol Selection (Modbus RTU Example)
Allows selection of the desired communication
protocol by pressing on the desired option.
Activated:
Not Activated:
NOTE: After a parameter is created or modified, remember to press the button when prompted,
before leaving the active screen so that the parameter is stored or the action executed.
Node ID (Modbus RTU Example)
Allows setting of the desired node ID number
using the Numeric key pad generated by pressing
in the numerical field.
Nortech Protocol : 1 to 32
Modbus Protocol: 1 to 247
Press to exit or to confirm.
To Next Page
