Manual Flamcomat G4 + Flamcomat Starter G4
We reserve the right to change designs and technical specifications of our products.
28
ENG
7. Commissioning
7.1 Initial commissioning
• Document the commissioning procedure (actions and settings).
• Check that the installation and other actions prior to use have been carried out in full (e.g. power supply
available and connected, functioning or active fuses, seal tightness of the equipment, transport protection of
the volume sensor removed).
Commissioning is preferably done via Flamconnect App.
Caution: Ensure that the basic vessel is not filled until all the commissioning measures have been completed.
• Adjust the manual control valve on the pump module (see “Appendix 2.” on page 41). On the M02, the second
manual control valve must be set as well.
• Fill and de-aerate the heating or cooling system (not the vessel!)
• Check the operational readiness of the top-up line.
• Open the valve at the top-up connection and the lockshield valve at the flexible connection assembly (vessel
connection).
• SWITCH ON THE CONTROL UNIT and run the Commissioning procedure (“7.2 Overview menu options”
on page 29, Commissioning).
• Selecting your language is part of the Commissioning procedure.
• Then the Flamcomat basic vessel marking shall be scanned with the Flamconnect App, or shall be selected
based upon its nominal capacity (“5.3 Markings” on page 17, name-plate Vessel) and consequently
the factory-, operating calibration shall be performed. (“7.2 Overview menu options” on page 29)
• This start-up procedure is followed by activating the top-up procedure. Once a volume level of approx. 7%
has been reached (see display), SWITCH OFF THE CONTROL UNIT AND DE-AERATE THE PUMP(S) (“5.5
Component parts, vessels and connection assembly” on page 18; pos. 3.5 B; 3.6 B, pos. 3.20). On pumps with
automatic de-aeration, these must be opened by a single turn of the red cap on these components.
• Open the cap valve on the return circuit (system flow and return) Caution, the heating system pipes may be hot.
• Seal the lockshield valves.
• The completion of all the tasks to be carried out, the review of technical data, recommendations and
explanations in this manual lead to the pressure expansion automat being ready for operation.
• SWITCH ON THE CONTROL UNIT.
Balancing valves on the pump unit may not be closed during operation as doing so may cause severe/destructive
damage to the pump unit.
