101
Discovery, Discovery LXE, Pace Arrow, and Pace Arrow
Open panel to access
manual controls.
Set the On/Off switch
to the (I) position to use
manual controls. Position
(II) is for use with a remote
control (not all units).
Flame Action:
Turn the ame action
control knob to adjust
ame speed.
Light Dimmer Control:
Turn the knob to increase
or decrease brightness of
ame and embers.
Heater On/Off switch:
Supplies power to heating
element when main On/Off
switch is On.
Heater Thermostat
Control:
Turn the thermostat control
clockwise to increase
temperature setting or
counterclockwise to
decrease temperature
setting.
Thermal Over-
temperature Switch:
The replace is equipped
with a thermostat to
control room temperature.
In the event the replace
overheats, an automatic
over-temperature switch
will turn the replace off.
The replace can be reset
by switching the On/Off
switch to off and waiting
ve minutes before turning
the replace back on.
CAUTION:
Discontinue use and
contact a service technician
if frequently resetting the
fireplace.
Light Bulb Replacement:
Light bulbs should be replaced
when a section of the ame is
dark or when clarity and detail
diminishes. Two bulbs at the top
of the opening illuminate the log
exterior. Four bulbs under the log
simulate ames and embers. It is
recommended to replace all bulbs
as a set.
Remove the trim by pulling
straight forward.
Hold glass in place while
removing retaining top
clip.
Lift glass out and store in a
safe place.
WARNING:
To reduce the risk of fire
or electric shock, turn
off circuit breaker before
maintenance or cleaning.
CAUTION:
Use care when handling
the glass. Safety glass may
break if bumped, struck or
dropped.
NOTE:
Do not exceed 60 watts per
bulb. Verify brand and size
of bulb before obtaining
replacements. Allow at least
five minutes for bulbs to
cool before touching.
TIP:
Replace all bulbs if they
are close to the end of rated
life.
030979c
