FDA approved RV antifreeze
must be pumped through the Aqua-
Hot until the solution appears at
the hot water side of a faucet. The
on-board water pump can be used
(see illustration) to purge water
from the Aqua-Hot domestic water
loop.
Refer to the Aqua-Hot owner’s
manual for complete winterizing
instructions. If the system is
operating from AC electric and a
power outage occurs, extensive
damage to the Aqua-Hot may
occur.
CAUTION:
If the motorhome is hooked
to shore power during the
winter months and the
Aqua-Hot is operating
on the electric element, a
temporary power outage
can allow the system to
freeze resulting in damage.
NOTE:
Comfort heating can still
be used during transit if
the Aqua Hot has been
winterized.
Annual Tune Up
The Aqua-Hot requires an
annual tune up consisting of a
fuel nozzle, fuel lter replacement
and a thorough cleaning of the
combustion chamber. A tune up
will allow service personnel to
inspect for additional wear of other
components.
Signs that the Aqua-Hot may
need servicing are continuous
white exhaust smoke, poor
ignition start up or loss of heat
output. When in operation, the
Aqua-Hot should have a smooth,
high-pitched whine. Loud growls
or other abnormal noise indicates
service or repair is required.
Fuel Filter Replacement:
The fuel lter is located in a
curbside bay with the fuel tank.
As a guideline, change the lter
annually or at the rst indication
of heat loss. It is recommended to
carry an extra lter as one tank of
contaminated fuel can plug a fuel
lter. Replacement lters must
have a 10-micron rating.
Gar-ber Filter Number:
Model #R, 10 micron.
To Replace the Filter:
 Ensure the Aqua-Hot
Diesel switch at the galley
is turned off.
 Spin the lter
counterclockwise and
remove from head.
Remove old O-ring gasket.
 Install new O-ring supplied
with lter. Ensure the
gasket is seated in the
groove around the lter
canister.
Circulation
Pumps
AC Connection
Coolant Drain
Data Plate
Interlock
Switch
Fuel
Return
Fuel
Supply
Control
Module
Ignition
Coil
Webasto
Heater
040646e
Aqua-Hot fuel lter
090483b
