FlexGain PLEX - Page 9

User’s manual FlexGain Plex, V2
Version 1.3 9 from 99
E1
Е1
Network
Up to 8 FXS
V.35
Phone
Flex
Gain
Plex, V2
Router
Flex
Gain
Plex, V2
Up to 8 FXO
V.35
PBX
Router
Ethernet
Up to 8 VF channelsUp to 8 VF channels
E1
PBX
E1
PBX
Ethernet
E1
FG-Plex-E1 FG-Plex-E1
Figure 2. Scheme of multiplexing of analogue and digital interfaces into a digital E1 stream.
