FlexGain PLEX - 1.4.3 Interfaces and LEDs

User’s manual FlexGain Plex, V2
Version 1.3
20 from 99
1.4.3 Interfaces and LEDs.
Figure 5 shows the front panels of the devices of different mechanic designs. The
aspect ratio of different mechanic designs is not strict in this figure.
Table 2 presents the description of interfaces and LEDs.
Table 2. Interfaces and LEDs.
Availability
in different mechanic designs
Notations Description
Sub-Rack Mini-Rack Stand Alone
LEDs
E1 LED displaying the status of the Е1
port
• • •
V.35 LED displaying the status of the V.35-
port
• • •
1 LED displaying the status of the voice
P1 port
• • •
2 LED displaying the status of the voice
P2 port
• • •
3 LED displaying the status of the voice
P3 port
• • •
4 LED displaying the status of the voice
P4 port
• • •
5 LED displaying the status of the voice
P5 port
• • •
6 LED displaying the status of the voice
P6 port
• • •
7 LED displaying the status of the voice
P7 port
• • •
8 LED displaying the status of the voice
P8 port
• • •
Eth LED displaying the status of the
Ethernet port
• • •
- System LED (S)
• • •
Interfaces
E1 Е1 interface
• • •
Ethernet Ethernet interface
• • •
V.35 V.35 interface
• • •
1 Interface of the voice P1 port
• • •
2 Interface of the voice P2 port
• • •
3 Interface of the voice P3 port
• • •
4 Interface of the voice P4 port
• • •
5 Interface of the voice P5 port
• • •
6 Interface of the voice P6 port
• • •
7 Interface of the voice P7 port
• • •
8 Interface of the voice P8 port
• • •
-48VDC
Power connector (stationary or
battery) -48 V
o
• •
