9.2.3 Installation of an output
If the transmitter is equipped with outputs, they have to be
installed and activated before they can be used:
• assignment of a measuring channel (source channel) to
the output (if the transmitter has more than one measur-
ing channel)
• assignment of the physical quantity (source item) to be
transmitted to the output by the source channel, and the
properties of the signal
• definition of the output behavior in case no valid mea-
sured values are available
• activation of the installed output in the program branch
Output Options
In the following, the configuration of an analog outputs is described.
• Select the menu item Special Funct.\SYSTEM settings\Proc. outputs.
• Press ENTER.
Selection of an output
• Select the output to be installed.
• Press ENTER.
The scroll list contains all available outputs of the transmitter:
– Current Ix (--)
– Binary Bx (--)
– Frequency Fx (--)
A tick () after a list item indicates that this output has already been installed.
• Select yes to install or reconfigure the output.
• Press ENTER.
• Select no to uninstall the output and to return to the previous menu item in order to select another output.
• Press ENTER.
Assignment of a measuring channel
• Select the measuring channel to be assigned to the output as the source channel in the scroll list.
• Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.
SYSTEM settings
Proc. outputs
Install Output
Enable
Source chan.
Source item
see annex A, p. 172
Notice!
The settings will be stored at the end of the dialog. If the menu item is quit by pressing key BRK, the changes will not
be stored.
Special Funct.\SYSTEM settings\Proc. outputs
Special Funct.\SYSTEM settings\Proc. outputs\Install Output
Special Funct.\SYSTEM settings\Proc. outputs\Enable I1
Special Funct.\SYSTEM settings\Proc. outputs\...\I1 Source chan.
