A Menu Structure FLUXUS WD100, WD200
UMFLUXUS_F5WDV1-1EN, 2016-04-08 91
selection of the unit of measurement for the kinematic viscosity x
selection of the unit of measurement for the sound speed x
SYSTEM settings\Measuring
selection of the displays for the settings of the measurement
input of an upper limit of the flow velocity
range: 0.1...25.5 m/s
0 m/s: no detection for outliers
All measured values that are greater than the limit will be marked as outliers.
x
selection of the input of a lower limit for the flow velocity:
• absolut: independent of the flow direction
• sign: dependent on the flow direction
x
activation of the input of a lower limit of the flow velocity:
• factory: the default limit of 2.5 cm/s will be used
• user: input of a limit
x
input of the cut-off flow for positive measured values
range: 0...12.7 cm/s (0.127 m/s)
default: 2.5 cm/s (0.025 m/s)
This display will only be indicated if Cut-off Flow = sign and Cut-off
Flow = user has been selected.
x
input of the cut-off flow for negative measured values
range: -12.7...0 cm/s
default: -2.5 cm/s
This display will only be indicated if Cut-off Flow = sign and Cut-off
Flow = user has been selected.
x
input of the cut-off flow for the absolute value of the measured values
range: 0...12.7 cm/s
default: 2.5 cm/s
This display will only be indicated if Cut-off Flow = absolut and Cut-off
Flow = user has been selected.
x
input of the max. signal amplification
range: 0...255
0: no limit of the signal amplification
This display will only be indicated if the SuperUser mode is activated.
x
input of the fixed upper limit of the sound speed
range: 0...3 000 m/s
0: the default value 1 848 m/s is used
This display will only be indicated if the SuperUser mode is activated.
x
INIT-
resistant
Viscosity unit
mm2/s >cSt<
Soundspeed unit
>[m/s]< [fps]
SYSTEM settings↕
Measuring
Cut-off Flow
absolut >SIGN<
Cut-off Flow
factory >USER<
Gain threshold
Fail if > 90 dB
Bad soundspeed
thresh. 2007 m/s
To Next Page
